Circulating Fluidized Bed Utility CFB Boiler , Industrial Grade Cogeneration Plant

Circulating Fluidized Bed Utility CFB Boiler , Industrial Grade Cogeneration Plant

    • Circulating Fluidized Bed Utility CFB Boiler , Industrial Grade Cogeneration Plant
    • Circulating Fluidized Bed Utility CFB Boiler , Industrial Grade Cogeneration Plant
    • Circulating Fluidized Bed Utility CFB Boiler , Industrial Grade Cogeneration Plant
    • Circulating Fluidized Bed Utility CFB Boiler , Industrial Grade Cogeneration Plant
  • Circulating Fluidized Bed Utility CFB Boiler , Industrial Grade Cogeneration Plant

    পণ্যের বিবরণ:

    Place of Origin: Zhangjiagang,China
    পরিচিতিমুলক নাম: HD Boiler
    সাক্ষ্যদান: ISO9001,ASME,Grade A,SGS,EN,TUV
    Model Number: CFB Boiler

    প্রদান:

    Minimum Order Quantity: 1 Set
    মূল্য: Negotiable
    Packaging Details: Seaworthy Packing
    Delivery Time: Negotiation
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 Sets / Year
    এখন যোগাযোগ
    বিস্তারিত পণ্যের বর্ণনা
    Condition: New Structure: Fluidized bed
    Fuel: Coal / Biomass Water Circulation: Natural circulation
    Specification: Customized Pressure: High Pressure
    Range of Applications: Industrial and utility Place Style: Vertical

    Circulating Fluidized Bed Combustion utility and industrial grade cogenerationg plant


    Product Description



    The circulating fluidized bed (CFB) is a developing technology for coal combustion to achieve lower emission of pollutants. By using this technology, up to 95% of pollutants can be absorbed before being emitted to the atmosphere.



    Parameter


    Model Capacity (t/h)

    Pressure

    (MPa)

    Steam temperature

    (ºC)

    Feed water temperature
    (ºC)

    Desulfurization efficiency

    (%)

    HD-35/3.82-M 35 3.82 450 150 min 82
    HD-35/5.3-M 35 5.3 450 150 min 82
    HD-75/3.82-M 75 3.82 450 150 min 82
    HD-75/5.3-M 75 5.3 485 150 min 82
    HD-75/9.8-M1 75 9.8 540 215 min 82
    HD-130/3.82-M 130 3.82 450 172 min 82
    HD-130/5.3-M 130 5.3 485 172 min 82
    HD-130/9.8-M 130 9.8 540 215 min 82



    Structure Features



    • Natural circulation water-tube boiler single boiler barrel, an n-shaped structure.
    The hearth is membrane water wall hanging closed structure.
    Adopting the water cooling air chamber and a water cooling cloth wind plate, under the bed of water.
    Separated by high temperature insulation volute cyclone cylinder, outer furnace arrangement.
    Superheater, economizer, air preheater is arranged in the tail shaft.​​



    Benefits



    Greatest Fuel Flexibility

    • Best overall solution for high moisture fuels.
    • Ability to burn fuels containing mid-level amounts of alkali.
    • Proficient at combusting fuels from the extreme low-end to extreme high-end moisture contents.



    Higher Efficiencies

    • Lowest excess oxygen required for complete combustion.
    • Lowest unburned carbon.



    Highest Allowable Outputs

    • Highest Pressure.
    • Highest Temperature.
    • Steam Flow (up to 1,000,000 PPH).



    Lowest Uncontrolled Emissions of NOx, SO2, CO, VOC’s and PM.



    Quality Control



    1. Fabrication area of 400,000 square meters

    2. 150 Engineers

    3. 600 Coded welders

    4. 60 Licensed Inspectors(NDT Level-III instructors)

    5. Class-A Licenses for Design and Manufacture Boiler

    6. ISO 9001:2008 Quality System

    7. ASME Certificate of Power Boilers

    8.ASME 'S','U' and NB stamp authorization

    Circulating Fluidized Bed Utility CFB Boiler , Industrial Grade Cogeneration Plant



    Company Introduction



    Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.



    Circulating Fluidized Bed Utility CFB Boiler , Industrial Grade Cogeneration Plant
